Nova F 410
Non-returnable
$10,975.00 - $11,575.00
The Nova F 410 T is a heavy duty, long bed 16” jointer designed to meet the needs of the most demanding environments. It features cast iron tables, tilting fence, and a quick change Tersa or Spiral Cutterhead.
Cutterhead
Choose Quantity
Product Details
TECHNICAL SPECIFICATIONS
Motor Horsepower 8 HP (3-Phase)
Total Table Length 2610mm (102 3/4”)
Infeed Table Length 1450mm (57”)
Outfeed Table Length 1160mm (45 1/2")
Table Width 410mm (16 1/8”)
Working Capacity 2600mm x 410mm (102 3/8” x 16 1/8”)
Max. Depth of Cut 8mm (5/16”)
Cutter Head Diameter 120mm (4 3/4")
RPM 5000
No. of knives 4 / Spiral Head With 68 Square Knives
Knife Dimensions 410mm x 35mm x 3mm / Square 15 x15x 2.5mm
Fence Size 1200mm x 190mm (47 1/4" x 7 1/2")
Fence Tilt 0° – 45°
Dust Hood Diameter 120mm
Noise Level (dB) 75
Overall Dimensions 105" x 44"
Shipping Weight 970kg (2,140 lbs.)
Net Weight 840 kg (1,851 lbs.)
Electrical Requirements 230 volt
Dust Extraction 980 cfm
