Machine Specs: • Worktable Dimension: 600mm x 885mm • Cast Iron Saw Wheels Diameter: 640mm • Saw Wheel Width: 38mm • Maximum Cutting Height: 600mm (24″) • Maximum Cutting Width: 620mm • Worktable Tilting (CE): 0° – 45° (20°) • Exhaust Outlet Diameter: N° 2mm x 120mm • Voltage: 220V 1-phase, 4.8hp, 25.2″ flywheels dia. , 23.6″ resaw height, 24.4″ cutting width, 204″ recommended blade length, .25″ – 1.5″ blade

Technical Specifications Worktable dimensions: 600 x 885 mm Diameter of cast iron saw wheels: 640 mm Saw wheels width: 38 mm Max. cutting height: 600 mm / 24″ Max. cutting width: 620 mm / 25″ Tilt of worktable: 0° / 20° Min./max. saw blade dimensions: 8 mm / 35 mm Standard single-phase motor S1 220V: 2.2kW (3hp) 50Hz Standard three-phase motor S1 400V 50Hz: 3kW (4hp) 50Hz Exhaust outlet diameter: 2 x 120mm 3-phase, 9hp, 25.2″ flywheels dia., 23.6″ resaw height, 24.4″ cutting width, 204″ recommended blade length, .25″ – 1.5″ blade widt

Technical Specifications Motor 3-phase 230v 6.6Hp Flywheel Diameter 29” (740mm) Table Size 28.34” x 39.37” (720x 1000mm) Table Tilt 0° -45 Cutting Height/Depth 17.7” (450mm) Cutting Width 28.34” (720mm) Min Blade Length 210.23” (5340mm) Max Blade Length 213.38” (5420mm) Overall Dimensions(Used Upright/Vertically) 46.4” x 28.3” x 104.3” (118x 72x 265cm) Net Weight 992lbs (450 kg) Total Dust Extraction Ports: 2 Total Dust Extraction Ports Diameter4.72” (120mm) 3-phase, 6.6hp, 29″ flywheel dia., 17.7″ resaw height, 28.34″ cutting width, 212″ recommended blade length, .31″ – 1.5″ blade width

Technical Specifications Motor 3-phase 230v Horsepower 9Hp Flywheel Diameter37” (940mm) Table Size32.28” x 45.66” (820x 1160mm) Table Tilt0° -45°Cutting Height/Depth22” (560mm)Cutting Width36.2” (920mm) MinBlade Length259.44” (6590mm) Max Blade Length264.17” (6710mm) Overall Dimensions(Used Upright/Vertically)61” x 36.2” x 112.59” (155x 92x 286cm) Net Weight1,584 lbs.(720kg) Total Dust Extraction Ports2 Total Dust Extraction Ports Diameter5.5” (140mm)

10′ Sliding table saw Heavy Duty Construction 126″ max length of cross cut 50″ rip capacity 7.5 hp main motor 1hp scoring motor 14″ blade capacity 30mm arbor Motorized Height adjustment of the main blade Manual Tilting arbor from 0 to 45 degrees Overarm dust collection included Heavy Industrial Aluminum cross cut fence with two flip stops 220v, 3 phase 60hz

The advantages of an exclusive choice. Buying a “L’invincibile six” machine means you get a customized solution, thanks to experience, technical research and Italian creativity. Console eye-S main functions: – connectivity among machines belonging to the same company network and 4.0 Industry preset – sharing of work programs and tools database – activity monitoring and reporting on the use of the machine – connectivity with SCM Thundercut (optimizer/sequencer App) – self-diagnosis, tele-service and link to troubleshooting

Maggi radial arm saws offer adaptability, versatility, precision and durability to shops of all sizes. Maggi has been producing radial arm saws since 1973 and over the years has continually improved technical design and quality. Heavy castings and the eight bearing saw carriage makes this machine very accurate and rigid. European quality made to last! 4 HP, 2800 RPM motor 400 mm (15.75") Blade diameter capacity (Not included) 30 mm Arbor diameter 73.23" x 45.08" Table size 27.75" Max crosscut length on 3/4" thick material (90 deg) 0 to 40.5" Rip capacity 4.9" Max depth of cut 19.68" Max cut length at 45 deg on right side 12.20" Max cut length at 45 deg on left side Dust chute on blade guard as well as rear of table Machine weight: 495 Lbs. Machine dimensions: 73" x 62" x 61" T Crated dimensions: 56" x 34" x 24" T Crated weight: 523 Lbs. Voltage: 230V 3-Phase

Our longest selling bandsaw, the S 45N set the bar high for quality bandsaws. This machine has 18” cast iron flywheels, and a large cast-iron table. With 12” resaw height it is also versatile to do either pattern work, or resawing operations! This machine has been a reliable tool in the Minimax lineup for over 30 years.

The precise, cost-effective and compact circular saw with tilting blade for the D.I.Y. woodworkers and small joineries. This entry-level sliding table saw, the Minimax SC 2C is a proven design based on years of experience. It is perfect for customers upgrading to their first slider from a table saw. The footprint is small, but the capacity is large. A compact chassis, powerful 3.4hp motor, and 5.5′ sliding table. A great step up from the standard American-style cabinet saw. – 5.5ft Sliding table saw with 12″ main blade – 3.4 Horsepower single-phase motor – Anodized aluminum sliding table with hardened steel ways – Micro-adjustable rip fence with cam-locking system – Telescopic crosscut fence with two flip stops – Dedicated scoring assembly independently adjustable – Eccentric workpiece clamp – External scoring adjustments – Adjustable and removable riving knife – Outfeed table extension – Outrigger support – Tool set and operator’s manual 1-phase, 3.4hp, 5.5′ sliding stroke, tilting 12″ main blade, belt driven scoring blade, 50″ rip capacity

The prefect entry-level production machine for small cabinet shops or serious hobbyists. Affordable, without compromising quality. Solid cast iron saw unit with double trunnions and independently adjustable scoring unit. Our brand new sliding table saw, the Elite series has proven itself in American cabinet shops for many years. This machine boasts a full 8.5’ stroke and features normally found on much more expensive machines, for a fraction of the cost. See for yourself why the Minimax SC 4E 8.5 foot machine stands in a class of its own. – Solid cast iron saw unit with double support trunnions – Aluminum sliding table and rail with hardened steel guide-ways – European-style rip fence with cam lock, micro-adjustable – Automatic self-braking motor – Round steel guide bar for rip fence – Double trunnions on both saw and shaper assemblies – Telescoping crosscut fence with two adjustable flip stops – An additional table on the sliding table for support of panels with large dimensions – Eccentric panel clamp – 2-position sliding table lock – Table extension on saw out-feed – Scoring blade (adjusted independently of main blade) – ¾” DADO capability – Toolset and operator’s manual – “CSA” rated electrical components

The ideal 10.5ft single-phase sliding table saw for small cabinet shops or serious hobbyists. Affordable, without compromising quality. Maximum precision and stability with the blades lifting by means of “dove-tail” guides system and the saw unit tilting by means of two, large, lateral trunnions. The Minimax SI 315ES has proven itself in American cabinet shops for many years. This machine boasts a full 10.5’ stroke, single-phase motor and features normally found on much more expensive machines, for a fraction of the cost. STANDARD FEATURES – Double-hung cast iron trunnion – 4.8Hp single-phase motor – Aluminum table and rail with hardened steel guideways – Two aluminum flip-stops on the crosscut fence – European rip fence with cam-lock, micro-adjustable – Telescoping crosscut fence with two adjustable flip stops – Automatic self-braking motor – Eccentric panel clamp – Telescoping miter gauge with fence and support panel – 2-Position sliding table lock – Dial indicator for saw blade tilt angle – Metric and standard rule on the crosscut fence – Table extension on saw out-feed – External scoring adjustments – 3/4” dado capacity – Telescoping support arm for crosscut support table – Toolset & operator’s manual – “CSA”-rated electrical component - 10.5' Slider - 12" tilting blade - 50" rip capacity - Independent scoring unit

Specifications: Motor: 3 HP, 1 PH, 12A, 230 V, Prewired 230 V Cutting Capacity Width: 14-1/2” Cutting Capacity Height: 14″ Blade Width: 1/8″ to 1″ Blade Speed: 3100 SFPM Blade Length: 153″ Table Dimension (LxW): 21-1/2” x 16″ Table Tilt: 10 ° left, 45 ° right Table Height from Floor: 40″ Table Height at 90 degrees: 40″ Miter Gauge Positive Stops: 45 degree, 90 degree Dust Port Outer Diameter: 4″ Dust Collection Minimum CFM: 600 cu.ft/min Thickness Capacity (max): 14″ Wheel Diameter: 15″ Dimensions: 83-1/2” H x 27-1/2” W x 29-3/4” L

The PWBS-14CS Bandsaw has an extra large, two-piece cast iron table. It consists of a 15 x 15″ tilting section and a fixed 15″ x 5″ extension for a total working surface area of 15″ x 20″. A balanced, nine-spoke cast iron wheel makes for smooth blade travel, and a Carter™ quick tension release lever makes blade changing easy. A micro-adjustable dual bearing blade guide system is featured above and below the table, as well as a work lamp and chip blower. A Poly-V belt maximizes power transmission while minimizing noise and vibration. It has full 6″ under guide capacity with 13-1/2″ frame to blade clearance. The aluminum rip fence comes with a resaw attachment.

TECHNICAL FEATURES Blades tilting 90° ÷ 45° Max. saw blade diam. with scoring blade installed mm (in) 400 (15.75”) Max. saw blade projection from table at 90°/45° mm (in) 140/97(5.5 / 3.81”) Scoring blade diameter mm (in) 120 (4.75”) Squaring stroke mm (in) 3200 (10.5’) Cutting width on parallel fence mm (in) 1500 (62.94”) Other technical features: Three-phase motor 11kW (15hp) 60Hz Exhaust outlets diameter 120 (4.75”) MINIMUM INSTALLATION REQUIREMENTS Power absorption A 42 Voltage frequency 230V 60Hz

SCMI 10′ programmable sliding table saw Year 2004 Manual raise, lower and tilting of the main blade Main blade up to 14″ with 1″ arbor Include Scoring Overarm guard included but not shown in the photo Programmable controlled rip fence with digitals on the front of the machine 9hp main motor 230v, 3 phase 60hz

Technical data Max. saw blade diameter with mounted scorer 400 / 16 mm / inches Maximum saw blade projection from table to 90°/45° 140/97 5.5/3.8 mm / inches Cutting width on rip fence (Rip capacity) 1270 / 50 mm / inches Max. squaring stroke of sliding table saw 3200 / 126 mm / inches Three-phase motor 9,5 (50) - 11 (60) Hp / Hz

Technical data Max. saw blade diameter with mounted scorer 315 / 12 mm / inches Sawblade arbor size 25 / 1 mm / inches Maximum saw blade projection from table to 90°/45° 100/70 3.9/2.75 mm / inches Cutting width on rip fence (Rip capacity) 1270 / 50 mm / inches Max. squaring stroke of sliding table saw 1600 / 63 mm / inches Three-phase motor 11 Hp Indipendent scoring motor 1 Hp

Jobsite Saw PRO 1.5HP, 120V, 60Hz Inc. Cart & Dust Guard

Compact Table Saw – 15A,120V,60Hz

SAWSTOP PATENTED SAFETY SYSTEM: Stops a spinning blade on contact with skin. The blade stops in less than 5 milliseconds, and drops below the table, minimizing a potentially life-altering injury to a mere scratch. UNMATCHED QUALITY: The trunnion and arbor are built for precision, strength and stability. The gas piston elevation delivers smooth and easy adjustability. Table flatness is measured diagonally at 0. 010” maximum gap. DUST COLLECTION: 99% dust collection is delivered above the table with the included dust collection blade guard, and below the table with advanced shrouding around the blade. Available Overarm Dust Collection (Model # TSA-ODC, sold separately) routes dust away from the blade and into the 4” port. RELIABILITY: The Control Box houses the on-off switch, power paddle, and on-board computer, and constantly checks that all systems are working to reliably keep you safe.

SAWSTOP PATENTED SAFETY SYSTEM: Stops a spinning blade on contact with skin. The blade stops in less than 5 milliseconds, and drops below the table, minimizing a potentially life-altering injury to a mere scratch. UNMATCHED QUALITY: The trunnion and arbor are built for precision, strength and stability.

SAWSTOP PATENTED SAFETY SYSTEM: Stops a spinning blade on contact with skin. The blade stops in less than 5 milliseconds, and drops below the table, minimizing a potentially life-altering injury to a mere scratch. UNMATCHED QUALITY: The trunnion and arbor are built for precision, strength and stability. Poly v-ribbed belts reduce vibration and help ensure a great cut. Table flatness is measured diagonally at 0. 010” maximum gap. RELIABILITY: The Control Box houses the on-off switch, power paddle, and on-board computer, and constantly checks that all systems are working to reliably keep you safe. CONFIGURABILITY: Over 150 unique configurations, makes the Contractor Saw the most configurable SawStop saw. Adding a mobile base, sliding crosscut table or router table, are just a few of the ways to make this your ideal saw. UNIVERSAL PERFORMANCE: The Contractor Saw offers versatility, reliability and safety for a variety of users. The cast iron table top (Cast Iron Wing Assembly, CNS-CIWA, sold separately) creates a better-than-hybrid performance in the shop at an affordable price. 36-INCH T-GLIDE FENCE ASSEMBLY: The 36-inch T-Glide Fence & Rail are made of heavy-gauge steel for sure lockdown and reliably square cutting for years without deflection. • Horsepower 1.75hp • Phase 1 phase • Voltage 110v

Powermatic ArmorGlide PM1500T Bandsaw, 3HP, 1PH, 230V 1791500T Blade Speed: 3100 SFPM Cutting Capacity Width: 14-1/2'' Cutting Capacity Height: 14'' Blade Width: 1/8'' - 1'' Maximum Saw Blade Width: 1'' Table Size: 21-1/2'' x 16'' Table Height from Floor: 40'' Table Tilt (Deg.): 10 Left, 45 Right Table T-Slot: 3/4'' Minimum Saw Blade Width (In.): 1/8 Miter Gauge Positive Stops: 45, 90 Dust Collection Minimum CFM Required (CFM): 600 Motor Voltage: 230V Prewired Voltage: 230V Motor Current (Amps): 12 Motor Horsepower: 3 ArmorGlide Coating: Yes

GENERAL DATA gabbiani p80 Blade projection mm 80 (3.15”) Worktable height mm 950 (37.4”) Standard clamps q.ty 5 Total clamps for 33 version q.ty 7 CUTTING DIMENSIONS Version 33 mm 3300x3200 (130”x126”) AXES SPEED Variable saw carriage speed m/min 0 – 120 (0-393.7 ft/min) Variable pusher speed m/min 70 (229.7 ft/min) MAIN SAW BLADE Motor power (S6 -40%) - 60hz (star-delta start) Hp 15 Rotating speed – 60 hz rpm 5580 Blade diameter mm 340 (13.38”) Blade shaft diameter mm 80 (3.15”) SCORING SAW BLADE Motor power (S6 -40%) - 60hz Hp 2 Rotating speed – 60 hz rpm 7020 Scoring saw blade diameter mm 200 (7.87”) Scoring blade shaft diameter mm 80 (3.15”) INSTALLATION Installed motor power kW 12÷15 Machine voltage 230 V / 60 hz Compressed air consumption NL/min 300 Requested operating pressure bar 7 Extraction flow rate m3/h 2190 Exhaust speed m/sec 20 Exhaust outlet diameter mm 4x120

CSA Certified Motor: 7.5HP, 3PH, 230/460V, 18.4/9.2A L x W x H (In.): 48 x 38 x 43 Net Weight (lbs): 738 lbs. Gross Weight (lbs): 831 lbs. Style: Cabinet Saw Prewired Voltage (V.): 230 Table Height from Floor (In.): 35-1/4 Maximum Diameter of Dado (In.): 8 Arbor Speed (RPM): 4500 Maximum Rip Left of Blade (In.) 14 Table Size (In.): 26 x 38 Maximum Width of Dado (In.): 13/16 Blade Diameter (In.): 14 Table Type: Cast Iron Maximum Rip Right of Blade (In.): 50 Dust Port Outside Diameter (In.): 4 Table T-Slot (In.): 3/4 x 3/8 Arbor Diameter (In.): 1 Recommended Circuit Size (Amps.): 30 Dust Collection Minimum CFM Required (CFM): 600 Table Size with Extensions (In.): 48 x 38 Maximum Depth of Cut at 90 Degrees (In.): 5-1/8 Maximum Depth of Cut at 45 Degrees (In.): 3-1/2 Table in Front of Saw Blade at Maximum Depth of Cut (In.): 15-1/2

Specifications: Motor: 3HP, 1PH, 230V, 14.5A L x W x H (In.): 84.75 x 39.5 x 40.5 Net Weight (lbs): 629 lbs. Gross Weight (lbs): 704 lbs. Style: Cabinet Saw Table Height from Floor (In.): 35 Maximum Diameter of Dado (In.): 8 Arbor Speed (RPM): 4500 Maximum Rip Left of Blade (In.): 13-1/2 Table Size (In.): 22 x 30-1/2 Maximum Width of Dado (In.): 13/16 Blade Diameter (In.): 10 Table Type: Cast Iron Maximum Rip Right of Blade (In.): 50 Dust Port Outside Diameter (In.): 4 Table T-Slot (In.): 3/4 x 3/8 Arbor Diameter (In.): 5/8 Recommended Circuit Size (Amps.): 20 Dust Collection Minimum CFM Required (CFM): 400 Table Size with Extensions (In.): 42 x 30-1/2 Maximum Depth of Cut at 90 Degrees (In.): 3-1/8 Maximum Depth of Cut at 45 Degrees (In.): 2-1/8 Table in Front of Saw Blade at Maximum Depth of Cut (In.): 11-1/4

Specifications: Motor: 3 HP Motor Power: 230V Motor Phase: 1 PH single phase Amps: 4.9 Arbor Diameter: 5/8" Arbor Speed: 4500 RPM Blade Diameter: 10" Dust Collection Minimum: 400 CFM Dust Port O.D.: 4" Maximum Depth of Cut at 45 Degree: 2-1/8" Maximum Depth of Cut: 2-1/8 or 3-1/8" Maximum Diameter of Dado: 8" Maximum Rip Left of Blade:13-1/2" Maximum Rip Right of Blade: 50" Maximum Width of Dado: 13/16 T-Slot with Stops Table Type: Cast Iron 50" Rip Fence Router Lift Net Weight: 690 lbs. Ship Weight: 719 lbs. Overall Dimensions: Shipping 84-3/4"L x 39-1/8"W x 40-3/8" H Table Height from Floor: 35" Table in Front of Saw Blade at Maximum Depth of Cut: 10" Table Size: 30-1/2" L x 22" W Recommended Circuit Size: 20 Amp

specification: Router Lift Included Motor: 5HP, 1PH, 230V, 21A L x W x H (In.): 84.75 x 39.5 x 40.5 Net Weight (lbs): 662 lbs. Gross Weight (lbs): 739 lbs. Style: Cabinet Saw Table Height from Floor (In.): 35 Maximum Diameter of Dado (In.): 8 Arbor Speed (RPM): 4500 Maximum Rip Left of Blade (In.): 13-1/2 Table Size (In.): 22 x 30-1/2 Maximum Width of Dado (In.): 13/16 Blade Diameter (In.): 10 Table Type: Cast Iron Maximum Rip Right of Blade (In.): 50 Dust Port Outside Diameter (In.): 4 Table T-Slot (In.): 3/4 x 3/8 Arbor Diameter (In.): 5/8 Recommended Circuit Size (Amps.): 30 Dust Collection Minimum CFM Required (CFM): 400 Table Size with Extensions (In.): 42 x 30-1/2 Maximum Depth of Cut at 90 Degrees (In.): 3-1/8 Maximum Depth of Cut at 45 Degrees (In.): 2-1/8 Table in Front of Saw Blade at Maximum Depth of Cut (In.): 11-1/4

Specification: Motor: 5HP, 3PH, 230/460V, 13/6.5A L x W x H (In.): 84.75 x 39.5 x 40.5 Net Weight (lbs): 662 lbs. Gross Weight (lbs): 739 lbs. Style: Cabinet Saw Prewired Voltage (V.): 230 Table Height from Floor (In.): 35 Maximum Diameter of Dado (In.): 8 Arbor Speed (RPM): 4500 Maximum Rip Left of Blade (In.): 13-1/2 Table Size (In.): 22 x 30-1/2 Maximum Width of Dado (In.): 13/16 Blade Diameter (In.): 10 Table Type: Cast Iron Maximum Rip Right of Blade (In.): 50 Dust Port Outside Diameter (In.): 4 Table T-Slot (In.): 3/4 x 3/8 Arbor Diameter (In.): 5/8 Recommended Circuit Size (Amps.): 20 Dust Collection Minimum CFM Required (CFM): 400 Table Size with Extensions (In.): 42 x 30-1/2 Maximum Depth of Cut at 90 Degrees (In.): 3-1/8 Maximum Depth of Cut at 45 Degrees (In.): 2-1/8 Table in Front of Saw Blade at Maximum Depth of Cut (In.): 11-1/4

specification: Motor: 5HP, 3PH, 230/460V, 13/6.5A L x W x H (In.): 84.75 x 39.5 x 40.5 Net Weight (lbs): 644 lbs. Gross Weight (lbs): 719 lbs. Style: Cabinet Saw Prewired Voltage (V.): 230 Table Height from Floor (In.): 35 Maximum Diameter of Dado (In.): 8 Arbor Speed (RPM): 4500 Maximum Rip Left of Blade (In.): 13-1/2 Table Size (In.): 22 x 30-1/2 Maximum Width of Dado (In.): 13/16 Blade Diameter (In.): 10 Table Type: Cast Iron Maximum Rip Right of Blade (In.): 50 Dust Port Outside Diameter (In.): 4 Table T-Slot (In.): 3/4 x 3/8 Arbor Diameter (In.): 5/8 Recommended Circuit Size (Amps.): 20 Dust Collection Minimum CFM Required (CFM): 400 Table Size with Extensions (In.): 42 x 30-1/2 Maximum Depth of Cut at 90 Degrees (In.): 3-1/8 Maximum Depth of Cut at 45 Degrees (In.): 2-1/8 Table in Front of Saw Blade at Maximum Depth of Cut (In.): 11-1/4

Specifications: Power: 1-3/4 HP Voltage: 115 Volt (prewired) / 230V Recommended Circuit Size: 20A Motor Phase: 1 Phase Motor Speed: 1720 RPM Power Transfer: V-belt Power Cord and Plug: SJT 14AWGx3C, 6 ft., 5-15P plug Recommended Circuit Size: 20A (for 115V), 15A (for 230V) Sound Emission without Load: 75 dB at 3 ft. (900 mm) from blade Bandsaw Nominal Size: 14" Bandsaw Wheel Diameter: 14" Blade Length: 116" Blade Width: 1/8" to 3/4" Cutting Capacity: 12" W; 13.3" H Blade Speed: 3,000 SFPM Wheel Speed: 765 RPM Table Material: Ground cast iron Table Insert Material: Anodized aluminum Table Height: 40" Table Size: 21-1/2" x 17" Table T-Slot: 3/4" (x2) Table Tilt: 45° R Stand Type: Closed Frame Material: Steel Wheels: Cast iron Tires: Polyurethane Blade guides: Ball bearings, aluminum block Resaw Fence: Extruded aluminum Resaw Fence Size (L x W x H): 18-1/4" x 6" (463 x 155 mm) Dust Collection Minimum Required: 350 CFM Dust Port: 4" Outer Diameter (x2) Overall Assembled Dimensions (L x W x H): approximately 37" x 27-1/2" x 75-3/8" Footprint (L x W): 24-7/8" x 17-3/4" Net Weight (approx.): 300 lb.

Specifications: Motor Power: 1/2 HP Motor Phase: 1 Phase Motor Voltage: 115V Motor Amps: 3.4A Band Saw Size/Wheel Diameter: 10" Cutting Capacity - Width: 9-1/2" Cutting Capacity - Height: 4-1/8" Maximum Rip Left of Blade with Fence: 5" (125 mm) Maximum Rip Right of Blade w/Fence: 5" (125 mm) Blade Length: 67-1/2" Blade Speed: 2750 SFPM Overall Dimensions without Stand (L x W x H): 27" x 18" x 33" (686 x 457 x 838 mm) Overall Dimensions with Stand (L x W x H): 30" x 19-1/2" x 59-1/2" (762 x 496 x 1511 mm) Table Size (L x W): 13-1/8" L x 13-3/8" Table Size with Extension (L x W): 13-1/8" x 19" Table Tilt: 0° to 45° Maximum Saw Blade Width: 1/2" Minimum Saw Blade Width: 1/8" Table Height from Floor: 41-1/2" Dust Port Outside Diameter: 4" Net Weight: approximately 83 lbs. (36.4 kg) Stand Type: Open

Double Mitre Saw for "V" cutting and Picture Frames. Two 14" saw blades, 3 1/2" width capacity. Last generation vertical Double Mitre Saw from OMGA, the V 235 is the result of 30 years of experience in this field. This compact and powerful system counts with all features and patented devices that OMGA designed throughout the years, such as the ProfilBlock clamping system or the popular patented Scaled Tables to name a few. The vertical travel system along with its 2 powerful 2 HP motors, make of the V 235 the perfect choice for accuracy and toughness in a variety of application for the picture frame, cabinet and millwork industries. Because of its versatility the V 235 is well suited to be connected with our OMGA Stop TM creating a truly integrated system which can be configured in a variety of levels of automation to fulfill the most demanding mitering tasks. Optional equipment such as Scaled Table Extensions, Dust collecting Systems, additional Moveable Stops, Aluminum version Kit and others, can be added to further complete the standard machine.

• Wheels and a folding stand provide portability for your compact panel saw and allow you to move it around your shop as you see fit. • Standard Equipment: - 3 ¼ Hp, 15 amp industrial, Milwaukee Tool motor. - Folding Stand - Wheels - Zinc plated 1 ¾” steel guide tubes. - 4 Nylatron roller bearing systems. - Adjustable vertical and horizontal rulers. - Quick change from vertical to horizontal cutting. - Thin material pressure guard. - Injection-molded plastic material rollers. - Spring loaded counter balance system. - Integrated dust collection bonnet. - Extended warranty. - TUV certified to UL/CSA standards

The C4 model packs all of the features of the full-size saws into a portable 5′ frame and features a 50″ maximum crosscut. The maximum cutting height on the C5 Panel Saw is 64″, both machines include a Milwaukee Tool motor and have no differences besides the maximum cutting height. The C4 is designed for customers who have limited floor space or require transporting the saw to the work site. Photos are shown shown with a stand and wheels, which are optional accessories.

•The C5 portable panel saw features a 64″ maximum crosscut and cuts material up to 1.75″ thick. •This panel saw can travel to work sites and fit into shops with limited floor space. The only difference between this machine and the C4 Panel saw are the maximum crosscut lengths. •Standard Equipment: - Zinc plated 1 ¾” steel guide tubes. - Milwaukee Tool motor - 4 Nylatron roller bearing systems. - Adjustable vertical and horizontal rulers. - Quick change from vertical to horizontal cutting. - Thin material pressure guard. - Injection-molded plastic material rollers. - Spring loaded counter balance system. - Integrated dust collection bonnet. - Extended warranty. - TUV certified to UL/CSA standards

•Featuring a 10′ frame, and 50″maximum crosscut with an unlimited rip cut, this panel saw is a preferred solution for cutting 4′ X 8′ sheets of plywood. The H4 panel saw cuts within 1/32″ on a wide variety of panel materials up to 1¾” thick. •The H4 offers full-sized vertical panel saw productivity in economical machines. H-Series saws are used in all kinds of panel processing applications. •Standard Equipment: - 3 ¼ Hp, 15 amp industrial duty saw motor. - Zinc plated 1 ¾”steel guide tubes. - 4 Nylatron roller bearing systems. - Adjustable vertical and horizontal rulers. - Quick change from vertical to horizontal cutting. - Thin material pressure guard. - Injection-molded plastic material rollers. - Spring loaded counter balance system. - Integrated dust collection bonnet. - Extended warranty. - TUV certified to UL/CSA standards

• Our flagship H5 panel saws are ideally suited for customers looking for a full sized vertical panel saw at a very affordable price. This saw has a crosscutting height of 64″ while delivering an accuracy of 1/32″ straight and square. The only difference between this model and our H4 and H6 models are that the they provide 50″, and 74″ maximum crosscuts. • Standard Equipment - Zinc plated 1 ¾”steel guide tubes. - Milwaukee Tool motor - 4 Nylatron roller bearing systems. - Adjustable vertical and horizontal rulers. - Quick change from vertical to horizontal cutting. - Thin material pressure guard. - Injection-molded plastic material rollers. - Spring loaded counter balance system. - Integrated dust collection bonnet. - Extended warranty. - TUV certified to UL/CSA standards

• The H6 Panel Saw provide a 74″ crosscut, ideal for cutting a 10′ X 6′ piece of material, up to 1.75″ thick while only occupying 30 square feet of floor space. A motor made by Milwaukee Tool is currently used on the H6 vertical saw. • Standard Equipment - Zinc plated 1¾”steel guide tubes. - 4 Nylatron roller bearing systems. - Milwaukee Tool Motor - Adjustable vertical and horizontal rulers. - Quick change from vertical to horizontal cutting. - Thin material pressure guard. - Injection-molded plastic material rollers. - Spring loaded counter balance system. - Integrated dust collection bonnet. - Extended warranty. - TUV certified to UL/CSA standards

• The 6400 provides a 64″ maximum crosscut while the 6800 provides a 74″ maximum crosscut. The maximum ripcut (horizontal) is dependent on pushing the panel through. • Standard Equipment: - 3 Hp worm driven heavy-duty saw motor. - 10 ft. welded steel frame. - Chrome-plated 1 3/4″ guide tubes. - 8 Nylatron roller bearing systems. - Adjustable vertical and horizontal rulers. - Quick change from vertical to horizontal cutting. - Thin material pressure guard. - Solid aluminum material rollers. - Enclosed counterweight system. - Integrated dust collection bonnet. - TUV certified to UL/CSA standards.

• Featuring a heavy duty worm drive motor, additional steel frame supports, aluminum wheels and double bearings, this machine will deliver an accuracy of 1/64″. The 6800 can cut sheets up to 74″ without blinking an eye. • Standard Equipment: - 3 Hp worm driven heavy-duty saw motor. - 10 ft. welded steel frame. - Chrome-plated 1 3/4″ guide tubes. - 8 Nylatron roller bearing systems. - Adjustable vertical and horizontal rulers. - Quick change from vertical to horizontal cutting. - Thin material pressure guard. - Solid aluminum material rollers. - Enclosed counterweight system. - Integrated dust collection bonnet. - TUV certified to UL/CSA standards.

• The EF5 Vertical Panel Saw is designed for businesses cutting up to 8 hours daily, with multiple operators cutting throughout the day. The maximum crosscut on the EF5 is 64″, with a 1.75″ cut depth, and unlimited length ripcut. It includes a dust collection kit, upgraded aluminum rollers, and additional steel welded at a diagonal plane. The EF5 includes dust collection and is ready to connect to your vacuum of choice. • The smart, servo motor on the EF5 has been rigorously tested for several years by our engineers, and a few customers using several of our vertical panel saws in day-to-day operations. Our customers were instrumental in identifying changes along the multi-year process of developing this machine. It continuously performed in high usage settings with multiple operators, cutting continuously throughout the day. The motor is capable of being set between 500 and 5,500 revolutions per minute (RPM) and precise cuts can depend on appropriately setting the RPM.

•Heavy duty induction motors allow you to cut endlessly with an option of single or three phase power. All of our machines are built to last; the 7000 series gives you that extra motor efficiency with little to no maintenance required. Longevity within the 7000 is made possible by high induction motors supported by US precision machined components. •The 7000 Panel Saw cuts horizontally and vertically, within .015” straight and square, up to 2” thick. Shops with multiple operators and continuous cutting operations will see a strong return on investment with this machine.

• Built with many similarities as the 7000 model including high induction motors, key upgrades on the 7400 & 7400XL include:

• High production panel processing is now a reality. Cut material 2 1/8″ deep for 8+ hours per day and within .005″ straight and square. Every component of this saw represents quality and performance. Featuring three different motor configurations, heavy extruded beams with precise dual-vee bearings, and the sturdiest frame on the market, these top of the line woodworking tools will boost your shops production. The 13′ frame is only difference between this machine and the 7400-M panel saw. • Standard Equipment: - Continuous usage induction saw motor. - Welded steel frame and integrated stand system. - Dual V-track precision guide system. - Adjustable vertical and horizontal rulers. - Floating pressure saw foot. - Solid aluminum material rollers. - Enclosed counterweight system. - Dust collection ready. - 3 year warranty. - TUV certified to UL/CSA standards
